10% Openness

Print page



Maximum Fabric/Shade Width: 94″
UV Blockage: Approximately 90%
Composition: 100% Polyester
Fabric Weight: 3.39 oz/yd²
Fabric Thickness: 0.012″
Railroad Available: No
Printable Available: No
Fire Classification: NFPA 701-10 TM#1, California U.S. Title 19
Bacterial and Fungal Resistance: n/a
Operating System: RB 500 Operating System with manual chain and ANSI compliant cord tensioner, manual crank, and motorization

Note: Several factors determine the maximum length of fabric. Please send project-specific specifications to our quoting department for more information.

Care and Cleaning

Fabric should be spot cleaned with light soft detergent.


Fabric Properties - Thermal - Total Solar

Rs (%)As (%)Ts (%)

Fabric Properties - Optical

Rv (%)Tv (%)

Openness Factor (OF), Reflectance (Rs), Transmittance (Ts), Absorptance (As), VisibleLlight Transmittance (Tv), and Visible Light Reflectance (Rv) - Reflectance and transmittance are measured using ASTM E 903-96 “Solar Absorptance, Reflectance, and Transmittance of Materials Using Integrating Spheres.” The samples are tested using a Perkin Elmer Lambda 950 UV/Vis/NIR Spectrophotometer. Three representative swatches from each sample, or the number of provided samples, are tested for fenestration values and the results are averaged. Solar and light values are calculated using ASTM E891 “Tables for Terrestrial Direct Normal Solar Spectral Irradiance Tables for Air Mass 1.5.” Calculations for Rs and Rv are rounded to the nearest whole number. Numbers are represented as percentages (i.e. the number 10 represents 10%).
